Technical Description

The WTC-F4/F6 series drone radar flow measurement system is an unmanned flow measurement system developed for high-flood river surveys and field emergency monitoring. This system integrates a 24GHz radar flow velocity module, a 24-26GHz radar water level module, and a video system via a two-axis stabilized gimbal, and is mounted on a quadrotor/hexacopter drone. The system can be integrated with cross-sectional GIS to monitor flow velocity, water level, and discharge, and directly generate flow statistics that comply with hydrological standards.

Features

Three-in-one functions

●  Multi-sensor fusion, including a 24GHz radar flow velocity module, a 24-26GHz radar water level module, and a video system.

Simultaneous Measurement and Reporting

●  A single flight directly measures water surface velocity and level, transmitting data in real time to generate flow statistics that comply with hydrological regulations.

Split-screen live view

●  The video interface and flow measurement software interface are displayed split-screen on the ground, making field operations more intuitive.

Quick-release structure

●  The modular design allows for assembly and disassembly of the entire system in just 3-5 minutes. All components fit comfortably in a 26-inch rolling luggage case.

Guaranteed personnel safety

●  For high-flood testing, personnel can be deployed at any time, eliminating the need for patrol personnel to be near the floodwaters, ensuring high personnel safety.
